Electric/Hybrid Engine Specifications
- Type: Electric Propeller Engines or Combustion Engines (Gasoline, Nitro Fuels or Kerosine)
- Power Source: High-capacity lithium-polymer batteries or/and Gasoline, Nitro Fuels or Kerosine
- Key Features: Low noise, zero emissions, high efficiency
Airframe Design and Materials - Material: Lightweight composite materials (carbon fiber, fiberglass)
- Wingspan: 3-7 meters
- Length: 1,5-5 meters
- Height: 0,6-1.5 meters
- Benefits: Lightweight, high strength, aerodynamic efficiency
Performance Metrics
- Maximum Speed: 21-38m/s
- Cruising Speed: 100-130 km/h
- Service Ceiling: 1,000-3,000 meters
- Range: 120-800 kilometers
- Endurance: 1-8 hours
Advanced Avionics and Navigation
- 1-3 Navigation System: GNSS/INS
- Autopilot: Advanced autopilot with multiple redundant fail-safes
- Communication: Real-time data link, secure communication
- Sensors: High-definition cameras, LIDAR, infrared sensor
Payload Capabilities - Capacity: <50kg
- Types: Surveillance equipment, scientific instruments, delivery packages
- Mounting Options: Modular mounting points for various payloads
Control Systems
- Ground Control Station: Portable with intuitive user interface
- Control Range: standard up to 50 kilometers (line of sight), extended with different signals up to 1000km
Safety and Redundancy
- Redundant Systems: Dual redundant flight control systems, multiple communication channels
- Emergency Systems: Automatic return-to-home, obstacle avoidance, and collision detection
